Sigenergy SigenStor Battery
SigenStor is an all-in-one energy storage system designed for homes and businesses, bringing battery storage, energy management and EV charging together in one flexible solution.
Home > Solar Batteries > Sigenergy SigenStor Battery System
Smart Energy Storage with Sigenergy SigenStor
The SigenStor combines five essential energy functions in one integrated unit inverter, battery storage, power conversion system (PCS), EV DC charger and energy management system (EMS). Rather than installing separate components, you get a single system designed to work together from day one, reducing installation time and complexity for both homes and businesses.
Flexible Battery Storage
The SigenStor is built to grow with your energy needs. Start with a single 6.0 kWh or 9.0 kWh battery module and expand up to 54 kWh per stack by adding up to six modules. Multiple stacks can be connected in parallel for larger commercial applications. Whether you’re looking to reduce bills at home or maximise energy independence for your business, the modular design lets you scale without replacing the system.
Modules
Per stack
Stack
Warranty
Home EV Charging with SigenStor
The Sigenergy EV DC Charger allows you to charge an electric vehicle using energy from your solar panels and battery. It also supports Vehicle-to-Home (V2H) and Vehicle-to-Grid (V2G) functionality for compatible vehicles, giving you more flexibility in how you manage and use your stored energy.
- Charge your EV using available solar energy
- Support for bidirectional V2H and V2G charging
- Can be added to an existing battery system
- DC charging directly from your energy storage system
- Max. 25 kW stable bidirectional DC charging
SigenStor Battery Specifications
Power
Usable storage capacity
Total storage
Max charging / discharging
DIMENSIONS (W/H/D) & WEIGHT
62 kg / 78 kg
Key features
Fully integrated
5-in-One home energy storage system.
1–6 stackable battery modules
6–54 kWh capacity range per stack
Fast installation
Guided quick connectors between battery modules auto-plug once stacked.
Parallel connections for flexible battery configurations
Choose a single battery 6.0 kWh or 9.0 kWh or combine multiple batteries
SIGEN BATTERY 6.0 / 10.0 kWh
| Model | BAT-6.0 | BAT-10.0 |
|---|---|---|
| Battery type | LiFePO4 | LiFePO4 |
| Total energy capacity | 6.02 kWh | 9.04 kWh |
| Usable energy capacity | 6.0 kWh | 9.0 kWh |
| Battery module voltage range (single phase) | 300 – 600 V | 300 – 600 V |
| Battery module voltage range (three phase) | 600 – 900 V | 600 – 900 V |
| Max. charge / discharge power | 3000 W | 4600 W |
| Peak charge / discharge power (10 s) | 4500 W | 6900 W |
General Specifications
| Weight | 62 kg / 78 kg |
| Dimensions (W × H × D) | 767 mm × 270 mm × 265 mm |
| Storage temperature range | −25 °C to 60 °C |
| Operating temperature range | −20 °C to 55 °C |
| Relative humidity range | 5% – 95% |
| Max. operating altitude | 4000 m |
| Cooling | Natural convection |
| System ingress protection rating | IP66 |
| Installation method | Floor standing / wall-mounted |
| Standard compliance | IEC/EN 60730-1, UN 38.3, IEC/EN 62619, IEC/EN 63056, IEC/EN 62040 |
Sigenergy Sigen Battery Datasheet (PDF) ↓
Manufacturer figures, current at time of publication. We confirm the exact module and inverter model on your quote.
Certified Sigenergy Installer
Easy Solar is a Sigenergy Certified Installer. Our team is trained and qualified to install the SigenStor battery system to the highest standards of safety and quality. When you choose Easy Solar, you’re backed by certified expertise and manufacturer-approved installation giving you full confidence in your energy storage investment.
Questions
FAQs
Have a question about SigenStor? Call 1300 646 419 to speak directly with the Easy Solar team about batteries, installation and your energy storage options.
Yes. The battery system can be fitted with an EV DC charging module, allowing compatible electric vehicles to use energy from your solar and battery system. Certain vehicles can also support bidirectional charging functions such as V2H and V2G.
Yes. You can start with a single 6.0 kWh or 9.0 kWh module and add up to six modules per stack, reaching up to 54 kWh. Multiple stacks can also be connected in parallel for larger setups.
Yes. SigenStor supports backup power when the grid goes down. The appliances you can run depend on your battery capacity and home’s electrical setup we assess this before installation.
Yes, with a Sigen Gateway fitted at the switchboard. It switches over in milliseconds and can back up the whole home or a set of essential circuits, depending on the stack’s discharge power. We work out which circuits matter before quoting.
